航空器加改装

公司具有专业的改装设计团队,改装范围涉及航空通讯、导航、电气、仪表、雷达、火控、气动和强度分析、计算、燃油、动力、外挂、机体结构等相关专业,擅长于使用激光扫描仪并结合相关计算机软件,对飞机外形进行扫描测绘、建模、仿真、辅助设计、计算分析、数控加工。

SAEC have a professional aircraft modification and designing team, the modified range includes the communication, NAV, electrical, instrument,radar, weapon-control system, pneumatic and strength analysis, calculation, fuel, power, external pods and airframe structure, etc. We are especially good at using laser scanner and the related computer software to R&D. For example,for aircraft shape scanning mapping, modeling, simulation, computer-aided design, calculation and analysis, numerical control processing.

先后为国内外陆、海、空军、航空公司客户在H6、Y5 、Y7、Y8、Y12、S550、AN26、M171、CESSNA208等机型成功实施火控系统、TCAS II 、GPS、EGPWS、VHF、HF/SSB 、APU 、FDR、应急地平仪、照相舱、人工增雨装置、跳伞舱门及航测系统的升级改装,总改装架次达到百余架。

SAEC team have completed the upgrading/modifying project of weapon-control system, GPS, TCAS II, VHF, HF/ SSB, emergency horizon, photography hatch and artificial rainfall device, parachuting hatch and aerial system for aircrafts of  H6, Y5,Y7, Y8, Y12, S550、AN26、M171 , CESSNA208.The total quantity has reached to more than 100 sorties.

在新技术研究方面,我公司与科研机构合作,共同进行机载双天线InSAR和稀疏阵三维成像雷达的系统集成和技术研究,并取得相关专利。通过奖状飞机改装双天线干涉成像雷达以及运12E飞机改装稀疏阵三维成像雷达的成功改装和试飞验证,达到了国际同等水平。

In study of new technique research,  SAEC  cooperates with the scientific research institutions to R&D techniques of airborne dual-antenna InSAR baseline project and the system integration of sparse array of three-dimensional imaging radar , and achieve the related patents. By successfully completing aircraft modification and flight test validation for dual-antenna interference imaging radar in S550 aircraft and sparse array of three-dimensional imaging radar modification work in Y12E aircraft , it proves  that the technique reaches the international level.




专利证书和验收证明

patent certificates and acceptance identification






某两型飞机家装航测设备

XX aircraft install aerial equipment




某型飞机加装应急地平仪及航测设备

XX aircraft install emergency horizon and aerial equipment

某型飞机加装卫星组合导航设备

xx aircraft install GPS




为中科院两架“奖状550”遥感飞机加改装TCASⅡ系统和FDR系统。2008年5月,经加改装的两架“奖状550”飞机立即投入到汶川抗震救灾行动中,经受了高强度飞行条件的考核并圆满完成任务。

Adding/modifying TCASII & FDR system for two S550 aircrafts. At May of 2008 year , the aircrafts were taken part in  rescuing action in Sichuan earthquake after modifying, and they overcame the strict flying conditions and completed task successfully.



APU改装、地面试车台及综合显控器

APU modification ,Ground Test Equipment and integrated display controller




为中国航空技术进出口公司出口国外的Y8F200等型号飞机加改装TCAS II、EGPWS、ELT、VHF、PA等系统。

SAEC added/modified TCASII, EGPWS, ELT, VHF ,PA and other system for Y8F200 ,which had been exported to foreign countries by CATIC.





从中国民航取得的STC证

Obtained STC from CAAC




Y12E飞机加装照相舱及人工增雨装置

modifying photographic hatch and artificial rainfall device on  Y12 E




奖状S550飞机改装双天线干涉成像雷达

modifying dual-antenna interference imaging radar in S550 aircraft




运12Ⅱ飞机改装稀疏阵三维成像雷达

modifying sparse array of three-dimensional imaging radar for Y12E aircraft




C90GTi 飞机外形测绘建模

aircraft shape scanning mapping, modeling for C90GTi




C90飞机数模和结构强度分析及论证

The  analysis of modulus and structural strength for C90 aircraft




CESSNA208/208B照相舱/跳伞门设计和改装

Designing and modifying camera compartment and skydiving gate for CESSNA208/208B




大棕熊飞机建模和照相舱设计

Airframe modeling and photography cabin designing for Kodiak
